| Technical Specifications | SN-1400 |
| Radar | 1 Navigation LiDAR + 2 Obstacle Avoidance LiDAR |
| External dimensions L*W*H | 1709*982*2117mm |
| Working road width | 2400mm |
| Lifting height | 1600mm |
| Fork face height above ground | 90mm |
| Self-weight | 900kg |
| Load capacity | 3000kg |
| Travel speed | 1.2 m/s |
| Fork Tine Dimensions l/e/s * | 1299*170*60mm |
| Fork Tip Obstacle Avoidance | Equipped |
| Spatial obstacle avoidance | Equipped |
| Pallet Identification | Equipped |
| Adaptable pallet | Chuan-style /nine leg pallet |
| Fork outer width | 540/680mm |
| Positioning accuracy | ±10mm/±1° |
| Battery type | Lithium iron phosphate |
| Capacity/Rated Voltage | 210Ah/24V |
| Charging time | ≦1.5H |
| Battery life | 6-8 hours |
| Multiple safety features | Emergency stop button, safety bumper, audible and visual warning signals |
| obstacle-crossing capability | 3%/5% (at full load/no load) |
| Communication | Support WiFi and seamless roaming；5G optional |
SN1400 Narrow-Aisle Stacker Robot
Designed for high-density warehouses and narrow-aisle storage applications, the SN1400 Narrow-Aisle Stacker Robot combines autonomous pallet transport and stacking in a compact footprint. With a 1,400 kg payload capacity, 1,600 mm lifting height, and optimized maneuverability, it operates efficiently in confined warehouse aisles where conventional forklifts have limited access, helping maximize storage density and warehouse utilization.
Powered by Laser SLAM navigation, intelligent pallet recognition, precision positioning, obstacle detection, and comprehensive industrial safety protection, the SN1400 performs autonomous pallet pickup, transport, stacking, and retrieval with exceptional accuracy and reliability. Compatible with both standard and nine-leg pallets, it provides an ideal automation solution for distribution centers, manufacturing facilities, and high-density warehousing operations seeking greater efficiency, improved safety, and more flexible intralogistics.
